1. lb部署keepalived

# 1.抢占式
LB01部署keepalived（master）
1.1 安装
[root@lb01 ~]#yum -y install keepalived
1.2 部署
```keepalived
[root@lb01 ~]#vim /etc/keepalived/keepalived.conf
global_defs {
    router_id lb01       #标识运行 Keepalived 的主机
}

vrrp_instance VI_1 {
    state MASTER
    interface ens33
    virtual_router_id 50  #虚拟id
    priority 150         	#优先级
    advert_int 1          #心跳间隔为1秒（组播）
    authentication {
        auth_type PASS
        auth_pass 1111    #组间密码
    }

    virtual_ipaddress {
        10.0.0.3          #vip（虚拟ip）
    }
}
```
1.3 启动keepalived服务
[root@lb01 ~]#systemctl start keepalived
[root@lb01 ~]#systemctl enable keepalived




# 2.LB02部署keepalived（backup）
2.1 安装
[root@lb02 ~]#yum -y install keepalived
2.2 部署
[root@lb02 ~]#cat /etc/keepalived/keepalived.conf
global_defs {
    router_id lb02							#改
}

vrrp_instance VI_1 {
    state BACKUP								#改
    interface ens33
    virtual_router_id 50
    priority 100								#低于master
    advert_int 1
    authentication {
        auth_type PASS
        auth_pass 1111
    }
    virtual_ipaddress {
        10.0.0.3
    }
}

2.3 启动keepalived服务
[root@lb02 ~]#systemctl start keepalived
[root@lb02 ~]#systemctl enable keepalived

# 2.非抢占式
 2.1 nopreempt  #只需加这个

 2.2 重启

F2
1. 默认情况下，当连续3 次接收不到主设备的 VRRP 通告时，备份设备就会认为主设备不可用

2. 模拟脑裂

# 1.开启防火墙
如果开启了防火墙,默认拒绝80和443的访问，只允许了SSH远程连接服务22端口
放行80和443端口
开启防火墙拒绝组播地址：IPv4: 224.0.0.18
[root@lb01 ~]#firewall-cmd --permanent --add-port=80/tcp
success
[root@lb01 ~]#firewall-cmd --permanent --add-port=443/tcp
success
[root@lb01 ~]#firewall-cmd --reload
success

# 抓包检查：[root@lb02 /etc/keepalived]#tcpdump -i ens33 vrrp -n

# 防火墙默认放行组播地址：# 查看防火墙是否允许 VRRP 协议
firewall-cmd --query-protocol=vrrp
输出应为 "yes"

# 关闭vrrp协议：
firewall-cmd --permanent --add-rich-rule='rule protocol value="vrrp" drop'
firewall-cmd --reload

# 开启vrrp协议
sudo firewall-cmd --permanent --add-rich-rule='rule protocol value="vrrp" accept'
sudo firewall-cmd --reload
或
 firewall-cmd --permanent --add-rich-rule='rule protocol value="112" accept'
 firewall-cmd --reload
注意：VRRP 协议 ≙ IP 协议号 112
     firewalld 中只有 IP 协议号是可靠识别方式，别名不一定有效。设置完记得手动开启关闭防火墙，才能生效

3. 解决脑裂脚本

3.1 LB02写出现脑裂则自动杀死当前的keepalived服务(必须为抢占式)

``` shell
#2.2.1 探测本机是否存在10.0.0.3 lb02变量的值要么1 要么是0 存在为1 不存在为0
lb02=`ip a|grep 10.0.0.3|wc -l`
#2.2.2 探测lb01是否存在10.0.0.3
lb01=`ssh 10.0.0.5 "ip a|grep 10.0.0.3"|wc -l`
#2.2.3 判断两台如果同时存在10.0.0.3则关闭本机的keepalived
[ $lb01 -eq 1 -a $lb02 -eq 1 ] && systemctl stop keepalived
#2.2.4 开启lb02的防火墙测试脚本是否执行成功
[root@lb02 ~]# systemctl start firewalld
[root@lb02 ~]# sh test.sh
#查看LB02是否杀死了keepalived
```

3.2 脚本探测nginx是否存在

[root@lb01 ~]#chmod +x chek.sh
[root@lb01 ~]#ll chek.sh
-rwxr-xr-x 1 root root 362 Apr 18 11:43 chek.sh

3.2 将脚本将keepalived结合
```shell
[root@lb01 ~]#cat /etc/keepalived/keepalived.conf
global_defs {
    router_id lb01
}

vrrp_script check_web {
    script "/root/chek.sh"		#指定脚本路径
    interval 3								#三秒执行一次
}

vrrp_instance VI_1 {
    state MASTER
    interface ens33
    virtual_router_id 50
    priority 150
    #nopreempt
    advert_int 1
    authentication {
        auth_type PASS
        auth_pass 1111
    }
    virtual_ipaddress {
        10.0.0.3
    }
    track_script {
    check_web										#检查脚本执行对错
    }
}
